PART NO. DESCRIPTIONREF NO. QTY.
Hydraulic Mount Group
Footnotes
NUT, 1/4-20 HEX NYLOCK FLANGE 1 5025391SM 4
BOLT, 3/8-16 X 1-1/4 GD5 2 5025013X10SM 2
WASHER, 3/8 SAE 3 5025156SM 6
NUT, 3/8-16 HEX NYLOCK FLANGE 4 5025394SM 6
BOLT, 1/4-20 X 3/4 GD5 YZ 5 5025010X6SM 4
WASHER, 1/4 SAE 6 5025154SM 4
WELD, HYD TANK MOUNT 7 5061747CSM 1
BRACKET, HYDRAULIC TANK 8 5061746CSM 2
BOLT, 3/8-16 X 1-1/2 GD5 YZ 9 5025013X12SM 4
The above parts group applies to the following Mfg. Nos.:
21
2009Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
5900707 - ZT4000B24
5900765 - ZT4000B26
TP 400-7340-M-50-S
