PART NO. DESCRIPTIONREF NO. QTY.
Seat Mount & Floor Group
Footnotes
BUMPER, RUBBER 5/16-18 1 5022612SM 2
NUT, 5/16-18 HEX NYLOCK FLANGE 2 5025392SM 9
WELD, SEAT PLATE - RED 3 5403392CSM 1
BOLT, 3/8-16 X 6" GD5 YZ 4 5025013X48SM 2
WASHER, 3/8" SAE 5 5025156SM 6
NUT, 3/8-16 HEX NYLOCK FLANGE 6 5025394SM 8
SAFETY WALK, 17.17 X 6.00 7 5101007SM 1
SAFETY WALK, 17.13 X 11.50 8 5100999SM 1
WELD, SEAT SUPPORT - ORG (S/N: 2012635841 & Below) 9 5402688CSM 1
BOLT, 3/8-16 X 1" GD5 YZ 10 5025013X8SM 4
SEAT, NO ARM REST 11 5100909SM 1
PLATE, FLOOR PAN, FRONT - IS500Z 12 5403389CSM 1
BOLT, 5/16-18 X 1" GD5 YZ 13 5025011X8SM 2
WASHER, 5/16" GD.9 FLAT 14 5025292SM 2
PLATE, FLOOR PAN, REAR - IS500Z 15 5403390CSM 1
MNT, VBRTN 16 197546SM 4
PLATE, SUPPORT, FRONT FLOOR 17 5403403CSM 1
BOLT, 5/16-18 X 5/8, FLANGE SERRATED 18 5025481SM 6
PLATE, SEAT SUPPORT, ZT4000 - ORG (S/N: 2012635842 & Above) 19 5403754CSM 1
KIT, ARM REST (SET OF TWO)(SV) 20 1686907SM 1
SPRING, SEAT ADJUSTMENT (SV) 21 5100636SM 1
KIT, SEAT RAILS (COMPLETE)(SV) 22 5061599X1SM 1
NUT, 5/16-18 HEX NYLOCK FLANGE SMALL 23 5025127SM 2
WASHER, 3/8" INT TOOTH LOCK 24 5025480SM 6
MTN, VBRTN, 30 DURO 25 35097SM 6
The above parts group applies to the following Mfg. Nos.:
23
2009Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
5900707 - ZT4000B24
5900765 - ZT4000B26
TP 400-7340-M-50-S
