Not for
Reproduction
PART NO. DESCRIPTIONREF NO. QTY.
Fuel Tank & Mount Group
Footnotes
TANK, FUEL, 1500Z - LH 1 5049947SM 1
TANK, FENDER, 1500Z - RH 2 5049948SM 1
FUEL CAP, 3.5", VENTED 3 5101272SM 1
BADGE, CITATION, ORANGE 4 5400250CSM 2
SCREW, #10-24 X 3/8 ALLEN BHBZ 5 5025386SM 6
BOLT, 5/16-18 X 1 GD5 YZ 6 5025011X8SM 10
WASHER, 5/16 GD.9 FLAT 7 5025292SM 10
WASHER, 5/16 LOCK YZ 8 5025170SM 10
MOUNT, TANK, FRONT 9 5400012CSM 2
BOLT, 3/8-16 X 1 GD5 YZ 10 5025013X8SM 2
WASHER, 3/8 GD.9 FLAT 11 5025293SM 2
NUT, 3/8-16 HEX NYLOCK FLANGE 12 5025394SM 2
BOLT, 3/8-16 X 1-1/4 GD5 13 5025013X10SM 4
WELD, TANK MOUNT-RH-IS500Z-ORG 14 5402557CSM 1
WELD, TANK MOUNT-LH-IS500Z-ORG 15 5402556CSM 1
GUAGE, FUEL LEVEL 16 5022917SM 2
GROMMET 17 5022917X1SM 2
CLAMP, HOSE, EXTERNAL, 1/2 18 5020835SM 2
HOSE, FUEL, 1/4 IN, LW PRMTN 19 5050831X22SM 1
SEE REF # 23 20 - -
SEE REF # 23 21 - -
SEE REF # 23 22 - -
HOSE ASSEMBLY 23 5101149SM 1
SEE REF # 23 24 - -
WIRE LOOM, 1/2 ID, 20.00 LONG 25 5050833X20SM 1
CABLE TIE, 12" (Not shown - Used to route fuel line.) 26 5021029SM 3
WIRE LOOM, 1/2 ID, 9.00 LONG (Not Shown - Between Filter and Engine) 27 5050833X9SM 1
The above parts group applies to the following Mfg. Nos.:
25
2009Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
5900707 - ZT4000B24
5900765 - ZT4000B26
TP 400-7340-M-50-S
