Page #27 background imageLoading...
Page #27 background image
Not for
Reproduction
PART NO. DESCRIPTIONREF NO. QTY.
Parking Brake Group
Footnotes
BOLT, 5/16-18 X 1-1/8 GD5 1 5025011X9SM 1
NUT, 5/16-18 HEX SERRATED FLANGE (LARGE) 2 5025139SM 2
BOLT, 5/16-18 X 3/4 12PT FLANGE - PATCH 3 5023490SM 8
WASHER, 5/16 USS 4 5025337SM 2
BOLT, 3/8-16 X 3/4 GD5 YZ 5 5025013X6SM 4
NUT, 3/8-16 HEX NYLOCK FLANGE 6 5025394SM 6
BOLT, 5/16-18 X 1-3/4 GD5 YZ 7 5025011X14SM 2
NUT, 5/16-18 HEX NYLOCK FLANGE 8 5025392SM 2
LINK, BRAKE STOP, 6.0 9 5061794CSM 2
BOLT, 3/8-16 X 1-1/2 GD5 YZ 10 5025013X12SM 2
NUT, 3/8-16 HEX SERRATED FLANGE 11 5025128SM 2
DRUM,1-1/4TAPER,5 BOLT 12 5023368SM 2
ASSM, BRAKE, 1-1/4 HUB, LH 13 5023500SM 1
ASSM, BRAKE, 1-1/4 HUB, RH (Not Shown) 14 5023501SM 1
SPACER, .32 X .75 X 1.06 15 5042134SM 2
BEARING, BRONZE FLANGE, 3/4 16 5021098SM 2
GRIP, BLACK FLEXIBLE (S/N: 2012619803 & Below) 17 5100171SM 1
SPACER, .38 X .50 X .27 18 5041930SM 2
WASHER, 3/8 SAE 19 5025156SM 2
SPRING, COMPRESSION 20 5023320SM 2
SPRING-COMP, .428ID X 2.50LG X .155WR 21 5022361SM 2
WASHER, 5/16 SAE 22 5025155SM 2
NUT, 5/16-24 HEX NYLON LOCK 23 5025045SM 2
CABLE, PARKING BRAKE 24 5023324SM 2
CLEVIS, 5/16-24, PLASTIC 25 5020979SM 2
NUT, 5/16-24 HEX 26 5025033SM 2
PIN, CLEVIS, 5/16 X 1 YZ 27 5025213X8SM 2
PIN, HAIR, .0585 X 1-1/8, 1/4 EYE, YZ 28 5025211SM 2
GROMMET, 1-1/4 29 5021397SM 2
WELD, BRAKE SHAFT (S/N: 2012619803 & Below) 30 5049831CSM 1
WELD, BRAKE SHAFT - ORANGE (S/N: 2012619804 & Above) 31 5403631CSM 1
GRIP, FOAM 3/4 ID X 6 X .187 (S/N: 2012619804 & Above) 32 5101038SM 1
The above parts group applies to the following Mfg. Nos.:
27
2009Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
5900707 - ZT4000B24
5900765 - ZT4000B26
TP 400-7340-M-50-S
