PART NO. DESCRIPTIONREF NO. QTY.

Main Frame & Front Suspension Group

Footnotes

SEAL, GREASE 1 5021072SM 2

SCREW, 5/16-18 X 1 FLAT HD SC 2 5025303SM 4

NUT, 5/16-18 HEX NYLON LOCK 3 5025057SM 4

WASHER, 3/8 FENDER 4 5025165SM 6

WASHER, 3/8 SAE 5 5025156SM 4

BOLT, 3/8-16 X 1-3/4 GD5 6 5025013X14SM 2

NUT, 3/8-16 HEX NYLOCK FLANGE 7 5025394SM 4

BOLT, 3/8-16 X 4 GD5 YZ 8 5025013X32SM 2

BOLT, 3/4-16 X 6-1/2 YZ GD5 9 5025265X52SM 1

WASHER, 3/4" SAE 10 5025160SM 4

NUT, 3/4-16 HEX NYLON LOCK 11 5025284SM 1

SHOCK, SPRING ASSEMBLY 12 5023483SM 2

WELD, CASTER YOKE, IS500Z - ORG 13 5402539CSM 2

BEARING, TAPERED ROLLER, 1" 14 5020884SM 4

WELD, FRONT PIVOT, CITATION - ORG 15 5402536CSM 1

SPACER, .75 X 1.00 X 2.38 16 5047489SM 1

PIVOT BEARING, 1.00" X 1.125" OD X 1.50" 17 5022852SM 1

PIVOT BEARING, 1.00 X 1.125 OD X .50 18 5100358SM 1

CAP, CASTER SPINDLE, LOW PROFILE 19 5100882SM 2

PAD, FRICTION, .375 X 1.25 X 4.00 20 5100930SM 2

WELD, IS500 MAIN FRAME - ORG 21 5403394CSM 1

WASHER, BELLEVILLE - 1.500 X .755 22 5025449SM 4

NUT, 3/4-16, HEX JAM NYLON LOCK 23 5025448SM 2

BEARING CUP 24 5020883SM 4

BOLT, 1/4-28 X 1/2, GD5 YZ 25 5025457SM 2

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

5900707 - ZT4000B24

5900765 - ZT4000B26

TP 400-7340-M-50-S
