PART NO. DESCRIPTIONREF NO. QTY.
Rear Bumper & ROPS Group
Footnotes
PLUG, PANEL, 1.25 - BLACK 1 5023484SM 6
SEAT BELT, RETRACTING - ASSM 2 5100139SM 1
SCREW, 1/2-13 X 1.00, SHCS 3 5100267SM 2
MOUNT, SEAT BELT - RH - ORG 4 5400847CSM 1
PLATE, SEAT BELT ANCHOR - LH - ORG 5 5400844CSM 1
SPACER, .52 X 1.00 X .75 6 5045178SM 1
SPACER, .515 X 1.00 X .218 7 5100520SM 1
ROPS, IS500Z 8 5101730SM 1
BOLT, 1/2-13 X 1-3/4, HHCS GD5 9 5100268SM 2
NUT, 1/2-13 HEX NYLOCK FLANGE 10 5025396SM 10
BOLT, 1/2-13 X 3-1/4, HEX HD, GD5, YZ 11 5025017X26SM 6
WASHER, 1/2 SAE 12 5025158SM 6
PLATE, HEAT SHIELD - IS500Z - ORG 13 5402618CSM 1
BODY CLIP, 5/16-18 X 1/2 DEEP 14 5022308SM 2
WASHER, 5/16 SAE 15 5025155SM 2
BOLT, 5/16-18 X 1 GD5 YZ 16 5025011X8SM 2
WELD, BUMPER - IS500Z - ORG 17 5402547CSM 1
CAP, VINYL - .750 X .50 - BLK 18 5101049SM 1
The above parts group applies to the following Mfg. Nos.:
7
2009Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
5900707 - ZT4000B24
5900765 - ZT4000B26
TP 400-7340-M-50-S
