PART NO. DESCRIPTIONREF NO. QTY.
Engine & PTO Group - 24HP & 26HP Briggs & Stratton
Footnotes
BOLT, CRANKSHAFT, 7/16X2-3/4, PATCH YZ 1 5047632SM 1
BOLT, 5/16-18 X 1-3/4 GD5 YZ 2 5025011X14SM 2
NUT, 5/16-18 HEX NYLOCK FLANGE 3 5025392SM 6
WASHER, 5/16" INT. TOOTH LOCK 4 5025188SM 2
CLUTCH ANCHOR PAD 5 5043636SM 1
WASHER, .34 X 1.25 X 10 GA 6 5044617SM 3
ANCHOR, CLUTCH 7 5046416CSM 1
BOLT, 5/16-18 X 2 GD5 TFL 8 5025055X16SM 1
BOLT, 5/16-18 X 1 GD5 YZ 9 5025011X8SM 2
BOLT, 5/16-18 X 3/4 GD5 10 5025011X6SM 2
KEY, 1/4 SQ. X 1.00 11 5050407X8SM 1
PULLEY, CRANKSHAFT 12 5100914SM 1
GROMMET, 7/8 13 5021379SM 2
WASHER, 5/16 SAE 14 5025155SM 8
NUT, 5/16-18 HEX SERRATED FLANGE (LARGE) 15 5025139SM 1
ENGINE-24HP B&S, ELS #44M777-0113-E1 (24HP Models Only) 16 - 1
CLUTCH, # 5219-34A, ELECTRIC, IS500Z 17 5100915SM 1
MUFFLER, B&S-ELS 22-26HP 18 5100907SM 1
CLAMP, VINYL INSULATED 19 5021500SM 1
WASHER, 1/4 SAE 20 5025154SM 1
NUT, 1/4-20 HEX NYLOCK FLANGE 21 5025391SM 1
BOLT, 1/4-20 X 3/4 GD5 YZ 22 5025010X6SM 1
HOSE, OIL DRAIN 23 5048681SM 1
PRE CLEANER (SV) 24 792303 1
AIR CLEANER W/ PRE CLEANER (SV) (Includes Ref. No. 24) 25 792105 1
BOLT, 5/16-18 X 1-1/2" GD5 YZ 26 5025011X12SM 2
OIL FILTER (NOT ILLUSTRATED) 27 696854 1
ENGINE-26HP B&S, ELS #44M777-0124-G1 (26HP Models Only) 28 - 1
WIRE LOOM, 1/2" PUSH-LOCK, 1.00" (Used on engine oil drain.) 29 5050833X11SM 1
The above parts group applies to the following Mfg. Nos.:
9
2009Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
5900707 - ZT4000B24
5900765 - ZT4000B26
TP 400-7340-M-50-S
