Step 12
B
N
E
L
E
R
First Door
(Right Door ER )
Second Door
(Left Door EL )
1. Slide the wheels on bottom of each door to the slots on Middle Shelf N .
2. Pull down the pins on top of each door then place the door to be parallel with the
medium storage side post. Afterward release the pins. The pins will be inserted
into the slots underneath of Top B .
3. To adjust the height of wheels up or down, use the Phillips screwdrive to rotate
the bolts on the wheels (Rotating clockwise will adjust the wheels higher, rotating
counter clockwise will adjust the wheels lower).
20
Model # AXCHRP-06-TKAssembly
