If your devices and module are set up as above and connections have been made (IP addresses are
used as examples) these connections are possible;
 Device 1 to Device 2
 Device 2 to Device 1
Also If you connect to the SMX-RNS02 module by using Wi-Fi as AP than you can access to Device 1
and Device 2.
Switch Chipset Features
Chipset
KSZ8895
Macs
5
Interface
MII/RMII
VLAN Support
Yes (up to 128 Pieces)
Programmable Speed Limitation
Yes
Static Mac
Yes (Up to 32 Admissions)
RSTP Support
Yes
Maximum Packet Size
2000 Bytes
Advanced Features
 VLAN IDENTITY Labeling/Sticker Removal
Option by Port
 Add or Remove IEEE 802.1p/q Tags per Port
Based on Input Port
 Percentage Controlled Broadcast Storm
Protection (Global and Per Port)
 Queue Tag Mode
 1.4Gbps High Performance Memory
Bandwidth and Shared Memory-Based
Switch Fabric with Completely Unblocked
Configuration
 GMP v1/v2 Surveillance (IPv4) Support for
Multi-ArcPacket Filtering
 IPv4 / IPv6 QoS Support
 Unknown Unicast/Multicast Address and
Unknown VID Packet Filtering Support
 Self-Address Filtering
 T-push-free (Jitter-Free) Pre-Package
Speed Rate Support
