9
5. DC MICROAMPERES:
Range: 0-50μA
Voltage Drop: 250mV
6. DC MILLIAMPERES:
Ranges: 0-1-10-100-500 mA
Voltage Drop (Approx.): 250 mV, 255 mV, 300 mV, 500 mV
7. DC AMPERES:
Range: 0-10A
Voltage Drop (Approx.): 255mV
NOTE: The 10A range is not internally fused.
8.
9. *ACCURACY:
DC Voltage Ranges: 2% of Full Scale
DC Current:
0-50 μA Range: 1.5% of Full Scale
Other Ranges: 2% of Full Scale
**AC Voltage
Ranges: 3% of Full Scale
Frequency Response: Referenced to 100 Hz (Figures 4-5 and 4-9)
Resistance Ranges:
R X 1: 2.5° of Arc
R X 100: 2°of Arc
R X 10,000: 2° of Arc
10. DECIBELS:
Range: -20 to +10 dB, -8 to +22 dB,
0 to +30 dB, +6 to +36 dB,
+20 to +50 dB
Reference Level: With zero dB power level equal to 1 mW across
a 600
line.
11. BATTERIES:
Voltage: 1.5V, 9V
NEDA No.: 13F, 1604A
12. FUSE: F1 1A, 250V, type 3AG, quick-acting Littlefuse Type
312001, F2 2A, 600V Littlefuse Type BLS or
2A 600V, Bussman Type BBS.
13. TEST LEADS: 1 red, 1 black, 48" long.
14. SIZE: 5½” x 7" x 3 “ (13.34 x 17.78 x 7.94 cm)
15. WEIGHT: 3 lbs. (1.359 kg)
16. ***RATED-CIRCUIT
TO-GROUND
VOLTAGE: 1000V AC/DC Max.
:ECNATSISE1RX0R01X0R00,01XR
egna0R00,2-0
000,002-0 M02-0
gnidaeRretne2C10021 000,021
nepOlanimoN
egatloVtiucriC
V5.1V5.1V9
trohSlanimoN
tnerruCtiucriC
Am52A1m52.1Aμ57
