INSTALLATION
Please follow the points below when installing your appliance:
USE AN AUTHORISED PERSON
As stated in the local municipal building codes and other relevant statutory regulations.
• Wiring connections must be in accordance with AS/NZS 3000 Wiring Rules and any particular conditions
of the local authority.
• Refer to data plate for rating information and circuit diagram. The data plate is positioned behind the
bottom of the oven door. The circuit diagram is positioned on the top panel of the appliance.
• A functional switch must be provided near the appliance in an accessible position.
Refer to AS/NZS 3000 clause 4.3.11
• Wiring must be protected against mechanical failure. Refer to AS/NZS 3000 clause 3.9
• A means of disconnection with a contact separation of at least 3mm must be supplied in the fixed wiring.
• To gain access to the mains connection terminals, remove the top panel by unscrewing the 2 assembly
screws.
Note: Where connection is made to a multi-phase 240V supply, the bridge piece must be removed from
between the active connections.
IMPORTANT: This appliance must be properly earthed.
• Do not lift the appliance by the door handles.
• Prepare the cupboard opening to match your appliance measurements. (See diagrams).
• Slide appliance into the cupboard, ensuring that the supply cable (where fitted) does not kink.
• To prevent tipping, use the screws supplied to secure your oven into the cupboard by fastening through
the 2 holes (underbench) or 4 holes (separate grill) to the front panel.
• For appliances fitted with a supply flexible cord, if the cord is damaged, it must be replaced by the
manufacturer or its service agent or similarly qualified person in order to avoid a hazard. The plug
must be accessible after installation.
• Where the appliance is built into a cabinet, the cabinet material must be capable of withstanding 85°C.
Installation into low temperature tolerant cabinetry (e.g. vinyl coated) may result in deterioration of the
low temperature coating by discolouring or bubbling.
• If the appliance is installed adjacent to vinyl-wrapped surfaces, use an installation kit available from
the vinyl-wrap supplier.
• Electrolux Home Products cannot accept responsibility for damage caused by installation into low
temperature tolerant cabinets.
• After installation, test and ensure that the appliance operates correctly before handing it over to the
customer.
IMPORTANT: Before you cook in your new oven:
• Make sure that the room is well ventilated (to allow smoke to escape).
• It may take several hours to totally eliminate the smell of the adhesive used in the insulation. It is best
to initially operate the oven with windows and doors open for 4-8 hours.
CAUTION: To avoid any potential hazard, you must follow our instructions below when you install
your appliance. Failure to install the appliance correctly could invalidate any warranty or liability
claims and lead to prosecution.
