Specications | V3100 User Manual
DSC RECEIVER
Modulation 1,300 Hz / 2,100 Hz FSK
Accuracy 1,200 bps ± 30 ppm
Spurious Response Rejection ≧ 70 dB for signal @ -104 dBm;
BER ≦ 1 %
Blocking ≧ 84 dB for signal @ -104 dBm;
BER ≦1 %
GNSS RECEIVER (INTEGRATED)
Receiving Channels 50 channels
Accuracy IEC 61108-1 compliant
Output Rate 1 Hz
Support: GPS, Gallieo, Beidou, GLONASS
POWER SUPPLY
Supply Voltage 12V / 24V DC, 3A
Power Consumption Typically less than 3W average @
12V DC
CONNECTION INTERFACE
GPS Antenna Connector Adaptor to SMA (incl. in box)
VHF Antenna Connector SO-239 (Female)
NMEA 2000 Micro-C standard connector
NMEA 0183 (RS-422) Support two NMEA 0183
interfaces
Default baud rate 38,400 &
4,800 bps
Configurable and separate Tx/Rx
baud rate
Standard IEC 61162-1 / IEC 61162-2
sentences
Silent Mode Setting Set by dedicated pins in the 12-
pin cable or by NMEA 2000 from
Navico MFD
Internal Alarm Relay Setting Set by dedicated pins in the 8-pin
cable
USB Mini-B type, waterproof
