SINAMICS G120 - Page 84

SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
DC link components
Braking resistors
4/84
Siemens D 11.1 · 2009
4
■ Integration
Braking resistors which are optionally available depending on the Power Module used
U = Base component
S = Lateral mounting
– = Not possible
■ Technical specifications
Frame size
FSA FSB FSC FSD FSE FSF FSGX
PM240 Power Module with integrated brake chopper without inte-
grated brake
chopper
Available frame sizes ✓ ✓ ✓ ✓ ✓ ✓ ✓
DC link components
Braking resistor U U S S S S S
PM250 Power Module with line-commutated energy recovery
Available frame sizes – – ✓ ✓ ✓ ✓ –
DC link components
Braking resistor
1)
– – –
1)
–
1)
–
1)
–
1)
–
PM260 Power Module with line-commutated energy recovery and integrated sine-wave filter
Available frame sizes – – – ✓ – ✓ –
DC link components
Braking resistor
1)
– – – –
1)
– –
1)
–
Line supply voltage
380 V … 480 V 3 AC
Braking resistor
6SE6400-4BD11-0AA0 6SL3201-0BE12-0AA0 6SE6400-4BD16-5CA0
Resistor Ω 390 160 56
Rated power P
DB
kW (hp) 0.1 (0.13) 0.2 (0.27) 0.65 (0.87)
Peak power P
max
(cycle time 12 s)
kW 2 4 11
Power connections Shielded cable Shielded cable Shielded cable
• Conductor cross-section mm
2
3 × 2.5 3 × 2.5 3 × 2.5
•Length m 0.5 0.5 0.9
Thermostatic switch (NC contact)
Max. contact load
250 V AC/2.5 A 250 V AC/2.5 A 250 V AC/2.5 A
Degree of protection IP20 IP20 IP20
Frame size FSA FSB FSC
Dimensions
• Width mm 72 153 185
•Height mm 230 329 285
•Depth mm 43.5 43.5 150
Possible as base component yes yes no
Weight, approx. kg 1 2 3.8
Suitable for
PM240 Power Module
Type 6SL3224-0BE13-7UA0
6SL3224-0BE15-5UA0
6SL3224-0BE17-5UA0
6SL3224-0BE21-1UA0
6SL3224-0BE21-5UA0
6SL3224-0BE22-2.A0
6SL3224-0BE23-0.A0
6SL3224-0BE24-0.A0
6SL3224-0BE25-5.A0
6SL3224-0BE27-5.A0
6SL3224-0BE31-1.A0
Frame size FSA FSB FSC
1)
Line-commutated energy recovery is possible in conjunction with a PM250
or PM260 Power Module. A braking resistor cannot be connected and is
not necessary.
