SINAMICS G120 - Page 85

SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
DC link components
Braking resistors
4/85
Siemens D 11.1 · 2009
4
■ Technical specifications
Line supply voltage
380 V … 480 V 3 AC
Braking resistor
6SE6400-
4BD21-2DA0
6SE6400-
4BD22-2EA1
6SE6400-
4BD24-0FA0
6SE6400-
4BD26-0FA0
Resistor Ω 27 15 8.2 5.5
Rated power P
DB
kW (hp) 1.2 (1.6) 2.2 (3.0) 4 (5) 5.6 (7.5)
Peak power P
max
(cycle time 12 s)
kW 24 44 80 120
Power connections M6 screw studs M6 screw studs M6 screw studs M6 screw studs
Thermostatic switch (NC contact)
Max. contact load
250 V AC/2.5 A 250 V AC/2.5 A 250 V AC/2.5 A 250 V AC/2.5 A
Degree of protection IP20 IP20 IP20 IP20
Frame size FSD FSE FSF FSF
Dimensions
• Width mm 270 326 395 526
•Height mm 515 301 650 301
•Depth mm 175 484 315 484
Possible as base component no no no no
Weight, approx. kg 7.4 11 16.7 17.5
Suitable for
PM240 Power Module
Type 6SL3224-0BE31-5.A0
6SL3224-0BE31-8.A0
6SL3224-0BE32-2.A0
6SL3224-0BE33-0.A0
6SL3224-0BE33-7.A0
6SL3224-0BE34-5.A0
6SL3224-0BE35-5.A0
6SL3224-0BE37-5.A0
6SL3224-0BE38-8UA0
6SL3224-0BE41-1UA0
Frame size FSD FSE FSF FSF
Line supply voltage
380 V … 480 V 3 AC
Braking resistor
6SL3000-1BE31-3AA0 6SL3000-1BE32-5AA0
Resistor Ω 4.4 2.2
Rated power P
DB
kW (hp) 25 (34) 50 (67)
Peak power P
max
(cycle time 15 s every 90 s)
kW 125 250
Power connections M10 screw stud M10 screw stud
Thermostatic switch (NC contact)
Max. contact load
250 V AC/2.5 A 250 V AC/2.5 A
Degree of protection IP20 IP20
Frame size FSGX FSGX
Dimensions
• Width mm 740 810
•Height mm 605 1325
•Depth mm 485 485
Possible as base component no no
Weight, approx. kg 50 120
Suitable for
PM240 Power Module
Type 6SL3224-0XE41-3UA0 6SL3224-0XE41-6UA0
6SL3224-0XE42-0UA0
Frame size FSGX FSGX
© Siemens AG 2009
