SINAMICS G120 - Page 87

SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
DC link components
Braking Modules
4/87
Siemens D 11.1 · 2009
4
■ Technical specifications
DC link voltage 510 … 720 V DC Braking Module
6SL3300-1AE32-5AA0
Power
• Rated power P
DB
50 kW (67 hp)
• Peak power P
15
250 kW
•Power P
20
200 kW
•Power P
40
100 kW
Activation thresholds
(adjustable via DIP switch)
774 V (factory setting)
or 673 V
Length of cable
to braking resistor, max.
50 m
Digital inputs
In accordance with IEC 61131-2 Type 1
• Voltage –3 … +30 V
• Low level (an open-circuit digital input is
interpreted as “low”)
–3 … +5 V
• High Level 15 … 30 V
• Current consumption at 24 V DC, typ. 10 mA
• Max. conductor cross-section 1.5 mm
2
Digital outputs
(continuously short-circuit proof)
• Voltage 24 V DC
• Load current per digital output, max. 500 mA
• Max. conductor cross-section 1.5 mm
2
R1/R2 connection M8 screw
• Max. conductor cross-section 50 mm
2
Weight, approx. 7.3 kg
Approvals cURus (File No.: E192450)
Suitable for installation in a PM240 Power Module Frame size FSGX
