5. Mounting Lenses
11
p-slr User Manual
The Sinar p-slr is supplied without lens. Sinar Photography AG oers a wide range of
Sinaron digital lenses with dierent focal length. In addition lenses from other suppliers
can be used with Sinar p-slr. For such lenses Sinar oers the respective lens boards
and the assembling. In order to safeguard the best possible quality, the mounting of the
lenses on a lensboard must be performed by Sinar Photography.
The front coupling frame of the Sinar p-slr is equipped with a snap latch, so no tools
are required for the attachment of the lens. The lens board is placed on the lower edge
of the frame and then latched in place at the upper edge of the coupling frame.
Sinar recommends testing the secure placement by checking the frame manually.
Mounting Lenses
Test the secure
placement by checking
the frame manually.
3
Release Lock for Lenses
This release lock serves as lens board holder to
secure the lens. Before attaching the lens the release
lock must be slightly pulled.
4
Snap Lock
1
Detaching the bellows
The bellows is detached by pressing the button on
the top right side of the coupling frame.
2
Detaching the lens
The lens is detached by pressing the button (2) on
the top left side of the coupling frame.
Slightly pull the release lock (3) at the same time and
remove the lens.
4
