Sinar P-SLR - Operating Elements of the Sinar p-slr View Camera; Focusing Controls; Shifting and Tilting Controls

To benet from the creative potential of the Sinar p3-df SLR view camera the following
operating elements are at your disposal:
Operating elements
of the camera
3. Operating Elements Sinar p-slr View Camera
5
p-slr User Manual
Security Advice:
Please check the secure
xation of the lever (7)
before you start
ne adjustments.
5
Micro meter drive to tilt the horizontal axis H
Turning knob to tilt the front standard.
6
Micro meter drive to swing the vertical axis V
Turning knob to swing the front standard.
7
Clamping lever for coarse tilt on
the horizontal axis H
Vertical alignment of the standards with tilted
camera. Furthermore for coarse tilt so that the full
range of the ne adjustments can be used when
dening the plane of sharpness.
1
Lever for Coarse Focusing
Coarse focusing is accomplished by moving the
standards into the right position before you start ne
adjustments with the ne focusing turning knob (2)
2
Fine focus gear with depth of eld scale
Turning knob to ne focus the selected
image section.
3
Micro meter drive for vertical shifting
Turning wheel to vertically adjust the rear standard.
4
Micro meter drive for horizontal shifting
Turning wheel to horizontally adjust the
rear standard.
5
4
3
7
6
211
