55cm
ACCESSORIES AND INSTALLATION OF HEAT EXHAUST HOSE
following dimension.
bent too much, it would easily cause malfunction.)
－
14
－
If the pipe are to be bent, please install it by considering
Wrong installation is shown in following figure (If the pipe is
