No Description Part Code Actualization Qty Price Code
1 Front Grill 22415010 1 AM
2 Front Panel Assy 01533058 1 AW
3 Axial Flow Fan 10335008 1 AQ
4 Drainage Plug none 0 -
5 Chassis Sub-assy 0120581601P 1 AU
6 Drainage Connecter 06123401 1 AA
7 Compressor and Fittings 00103920 1 BT
8 4-Way Valve 430004032 1 AX
9 4-Way Valve Assy + Fittings 03073274 1 BB
10 Capillary Tube 03015737 1 AD
11 Cut off Valve 07130239 1 AG
12 Right Side Plate Assy 0130329207 1 AP
13 Valve Support Sub-Assy 01705046P 1 AE
14 Cut off Valve 07133844 1 AQ
15 Handle 26233053 1 AE
16 Capacitor CBB65 none 0 -
17 Temperature Sensor 3900030902 1 AH
18 Wiring clamp none 0 -
19 Rear Grill 01475020 1 AL
20 Condenser Assy 011002000244 1 BR
21 Clapboard Sub-Assy 01235081 1 AL
22 Condenser Support Plate 01795031 0 AD
23 Motor Support Sub-Assy 01705067 1 AN
24 Coping Sub-Assy 000051000017 1 AQ
25 Left Side Plate 01305093P 1 AN
26 left handle none 0 -
27 Terminal Board 420101943 1 AD
28 Electric Box Assy 100002001124 1 BN
29 Electric Box Cover 20123028 1 AG
30 Main Board 300027000233 1 BL
31 Radiator 49013076 1 AR
32 Electric Box 20113027 1 AM
33 Capacitor CBB61 none 0 -
34 Electric box (fireproofing) none 0 -
35 Fan Motor 1501506402 1 BB
MODEL: ASH-24BIF Outdoor
