Sinclair ASH-18BIF User Manual

Technical Information
Service Manual
Parameter Unit Value
Model ASH-18BIF
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) W 5130(1200~6200)
Heating Capacity(Min~Max) W 5280(1200~6600)
Cooling Power Input(Min~Max) W 1580(350~2100)
Heating Power Input(Min~Max) W 1420(350~1600)
Cooling Current Input A 7.0
Heating Current Input A 6.3
Rated Input W 2600
Rated Current A 10.8
Air Flow Volume(SH/H/M//L/SL) m
3
/h 800/720/610/520/-
Dehumidifying Volume L/h 1.8
EER W/W 3.25
COP W/W 3.72
SEER W/W 6.1
SCOP W/W 4.0
Application Area m
2
23-34
Indoor
Unit
Indoor Unit Model ASH-18BIF/I
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Ф106X706
Cooling Speed(SH/H/M//L/SL) r/min 1230/1130/1030/800/-
Heating Speed(SH/H/M//L/SL) r/min 1350/1200/1050/900/-
Fan Motor Power Output W 35
Fan Motor RLA A 0.35
Fan Motor Capacitor μF 2.5
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф7
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm 715X25.4X304.8
Swing Motor Model MP35CJ
Swing Motor Power Output W 2.5
Fuse Current A 3.15
Sound Pressure Level(SH/H/M//L/SL) dB (A) 49/44/39/34/-
Sound Power Level(SH/H/M//L/SL) dB (A) 59/54/49/44/-
Dimension (WXHXD) mm 970X300X224
Dimension of Carton Box (LXWXH) mm 1038X380X305
Dimension of Package(LXWXH) mm 1041X383X320
Net Weight kg 13.5
Gross Weight kg 16.5
2.1 Specication Sheet
2. Specications

Sinclair ASH-18BIF Specifications

General

Brand	Sinclair
Model	ASH-18BIF
Category	Air Conditioner
Language	English
