Outdoor Unit Model ASH-18BIF/O
Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO.,LTD
Compressor Model QXF-B141ZF030A
Compressor Oil 68EP
Compressor Type Rotary
Compressor LRA. A 25
Compressor RLA A 6.5
Compressor Power Input W 1410
Compressor Overload Protector 1NT11L-6233/KSD115
℃
/HPC 115/95
Throttling Method Capillary
Set Temperature Range ºC 16~30
Cooling Operation Ambient Temperature
Range
ºC -15~43
Heating Operation Ambient Temperature
Range
ºC -22~24
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7.94
Condenser Rows-n Gap mm 2-1.4
Condenser Coil Length (LXDXW) mm 742X38.1X550
Fan Motor Speed rpm 780
Fan Motor Power Output W 60
Fan Motor RLA A 0.62
Fan Motor Capacitor μF /
Outdoor Unit Air Flow Volume m
3
/h 2400
Fan Type Axial-ow
Fan Diameter mm Ф445
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure
for the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 56/-/-
Sound Power Level (H/M/L) dB (A) 66/-/-
Dimension(WXHXD) mm 899X596X378
Dimension of Carton Box (LXWXH) mm 945X417X630
Dimension of Package(LXWXH) mm 948X420X645
Net Weight kg 39
Gross Weight kg 42
Refrigerant R32
Refrigerant Charge kg 0.9
Connection
Pipe
Connection Pipe Length m 5
Connection Pipe Gas Additional Charge g/m 16
Outer Diameter Liquid Pipe mm Ф6
Outer Diameter Gas Pipe mm Ф12
Max Distance Height m 10
Max Distance Length m 25
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
