Sinclair ASH-18BIF User Manual

Technical Information
Service Manual
Parameter Unit Value
Model ASH-24BIF
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) W 6450(2000~8200)
Heating Capacity(Min~Max) W 6450(2000~8500)
Cooling Power Input(Min~Max) W 1950(400~3000)
Heating Power Input(Min~Max) W 1735(450~3100)
Cooling Current Input A 8.4
Heating Current Input A 8.0
Rated Input W 3800
Rated Current A 13.48
Air Flow Volume(SH/H/M//L/SL) m
3
/h 1250/1050/950/850/-
Dehumidifying Volume L/h 2.0
EER W/W 3.3
COP W/W 3.71
SEER W/W 6.30
SCOP W/W 4.0
Application Area m
2
23-34
Indoor
Unit
Indoor Unit Model ASH-24BIF/I
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Φ108X830
Cooling Speed(SH/H/M//L/SL) r/min 1250/1000/900/800/-
Heating Speed(SH/H/M//L/SL) r/min 1250/1000/900/850/-
Fan Motor Power Output W 35
Fan Motor RLA A 0.35
Fan Motor Capacitor μF 3
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф7
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm 845X25.4X342.9
Swing Motor Model MP35CJ
Swing Motor Power Output W 2.5
Fuse Current A 3.15
Sound Pressure Level(SH/H/M//L/SL) dB (A) 49/44/41/39/-
Sound Power Level(SH/H/M//L/SL) dB (A) 63/59/56/53/-
Dimension (WXHXD) mm 1078X325X246
Dimension of Carton Box (LXWXH) mm 1145X410X335
Dimension of Package(LXWXH) mm 1148X413X350
Net Weight kg 16.5
Gross Weight kg 20
