Sinclair KJR-120G User Manual

1.Press the button every time, the louver swings 6 degrees.
2.Press and hold the button for 2 seconds,it turns into up-down swing mode,
press ti again to stop.
When the Up-Down swing function is activated,the mark appears. (Not applicable
to all the models)
The operation can refer to the following instructions for the unit with four Up-Down
louvers can be operated individually.
-0
-1
-2
-3
-4
1.Press the Swing button to activate the Up-Down adjusting
louver function.
The mark will flash.(Not applicable to all the models)
2.Pressing the button “+” RUĀā can select the movement
of four louvers.Each time you push the button,the wire
controller select in a sequence that goes from:(the icon
means the four louvers move at the same time.)
3. And then use Swing button to adjust the Up-Down airflow direction of the selected
louver.
-0
19
Use Swing button to adjust the Up-down airflow direction.
9. OPERATION
Swing function (For the unit without left & right auto swing function models)
Up-Down airflow direction and swing
Swing
Swing
-
+

Sinclair KJR-120G Specifications

General

Brand	Sinclair
Model	KJR-120G
Category	Controller
Language	English
