Sinclair MOBILE Series Service Manual

1
2
screw
screw
Disassemble decoration plate
Unscrew the screw on the decoration plate
bottom, lift the decoration plate upwards
to remove it. (note: need lift at full tilt
because of clasps on both sides)
clasp
display plate
Disassemble front panel
(1)Disassemble front panel: unscrew the 7
screws of front panel, lift the panel upwards
to remove it.
(2)Separate panel: after lift front panel,
remove the display of panel from clasp,
then the front panel can be separated.
11. Removal Procedure
