Sinclair MOBILE Series Service Manual

No Description Part Code
Note
Qty
Price
Code
1
Decorative Board sub-assy 20196011
1 AN
2
Decorative Board 20196006S
1 AK
3
Decorative Block 20196013
1 AC
4
Decorative Strip 20196012
1 AE
5
Front Panel 20006059
1 AW
6
Front Panel Sub-Assy 20006061
1 AL
7
Display Board 30567012
1 AS
8
Button 45036021
1 AE
9
Fan Motor 1501603903
1 AY
10
Motor holder (upper) 26156043
1 AU
11
Electric Box Assy 01406016
1 BC
12
Main Board 30137003
1 AZ
13
Ambient Temperature Sensor 390000451
1 AD
14
Tube Sensor 390000594
1 AD
15
Transformer 43110295
1 AH
16
Capacitor CBB65 33010743
1 AK
17
Capacitor CBB61 33010027
1 AE
18
Capacitor CBB61 33010025
1 AE
19
Electric Box Cover 01416010
1 AD
20
Chassis Sub-assy 01206038P
1 AF
21
Gear Sub-Assy 10546005
1 AC
22
Centrifugal Fan 10316058
1 AM
23
Guide Louver 1 10516051
1 AD
24
Guide Louver 2 10516052
1 AD
25
Diversion Circle (upper) 10376035
1 AE
26
Stepping Motor 1521210301
1 AF
27
Left Axile Bush 10512037
3 AB
28
Mid-Clapboard 20056095
1 AL
29
Water Tray 20186072
1 AM
30
Evaporator Assy 01006050
1 BH
31
Filter Sub-assy 11126011
1 AD
32
Rear Plate Sub-Assy 20056105
1 AU
33
backboard 1 20056096
1 AR
34
Remote control box 20116012
1 AD
35
Cover of Remote control box 20126072
1 AE
36
Cable Cross Plate 26116060
1 AD
37
Female Clip 70810302
1 AB
38
Condenser Assy 0110610301
1 BK
39
Motor holder b (lower) 26156046
1 AP
40
Fan Motor 1501603902
1 AY
41
Centrifugal Fan 10316058
1 AM
42
Diversion Circle (lower) 10376034
1 AP
43
Discharge Tube 03616079
1 AG
44
Capillary Sub-Assy 03006095
1 AU
45
Inhalation Tube 03626095
1 AK
46
Compressor and Fittings 00103781
1 BL
PART 1
MODEL: AMC-12AN

Sinclair MOBILE Series Specifications

General

Brand	Sinclair
Model	MOBILE Series
Category	Air Conditioner
Language	English
