Sinclair MULTI VARIABLE Series Service Manual

2
Service Manual
2. Specications
Model
MV-E14BI
Product Code CB228W08401
Power
supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Cooling capacity W 4100
Heating capacity W 4400
Cooling Power Input W 1200
Heating Power Input W 1180
Cooling Current Input A 5.32
Heating Current Input A 4.53
Rated Power Input W 1780
Rated Current A 7.90
SEER W/W 6.10
SCOP W/W 4.00
Outdoor
Unit
Compressor Trademark
ZHUHAI LANDA COMPRESSOR
CO.,LTD
Compressor Model QXA-B141zF030A
Compressor Refrigerant Oil Type RB68EP
Compressor Type Inverter Rotary
L.R.A A 25
Compressor Rated Load Amp (RLA) A 7.2
Compressor Power Input W 1440
Compressor Thermal Protector
1NT11L-6233 or HPC 115/95 or
KSD115
O
C
Throttling Method Electron expansion valve
Cooling Operation Ambient Temperature Range
O
C -15~43
Heating Operation Ambient Temperature Range
O
C -20~24
Condenser Material Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ9.52
Rows-Fin Gap(mm) mm 2-1.4
Coil length (l) X height (H) X coil width (L) mm 800X44X559
Fan Motor Speed (rpm) (H/M/L) rpm 900
Output of Fan Motor W 30
Fan Motor RLA A 0.39
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit m
3
/h 2600
Fan Type-Piece Axial-ow
Fan Diameter mm Φ438-116
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Dimension (WXHXD) mm 899X596X378
Dimension of Package (LXWXH) mm 945X417X630
Dimension of Package(LXWXH) mm 948X420X645
Net Weight kg 43
Gross Weight kg 46
efrigerant Charge
R32
Refrigerant Charge kg 1.40
