Sinclair MULTI VARIABLE Series Service Manual

4
Service Manual
Model MV-E18BI
Product Code CB228W08501
Power
supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Cooling capacity W 5200
Heating capacity W 5400
Cooling Power Input W 1450
Heating Power Input W 1300
Cooling Current Input A 6.43
Heating Current Input A 5.77
Rated Power Input W 1.78
Rated Current A 7.9
SEER W/W 3.59
SCOP W/W 4.15
Outdoor
Unit
Compressor Trademark
ZHUHAI LANDA COMPRESSOR
CO.,LTD
Compressor Model QXF-B141ZF030A
Compressor Refrigerant Oil Type 68DA
Compressor Type Inverter Rotary
L.R.A A 25
Compressor Rated Load Amp (RLA) A 6.5
Compressor Power Input W 1410
Compressor Thermal Protector
1NT11L-6233 or HPC 115/95 or
KSD115
O
C
Throttling Method Electron expansion valve
Cooling Operation Ambient Temperature Range
O
C -15~43
Heating Operation Ambient Temperature Range
O
C -20~24
Condenser Material Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ9.52
Rows-Fin Gap(mm) mm 19.05X22
Coil length (l) X height (H) X coil width (L) mm 760X44X559
Fan Motor Speed (rpm) rpm 800/900
Output of Fan Motor W 30
Fan Motor RLA A
0.39
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit m
3
/h 2600
Fan Type-Piece Axial-ow
Fan Diameter mm Φ438-116
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure for the
Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for the
Suction Side
MPa 2.5
Dimension (WXHXD) mm 899X378X596
Dimension of Package (LXWXH) mm 945X417X630
Dimension of Package(LXWXH) mm 948X420X645
Net Weight kg 43
Gross Weight kg 46
efrigerant Charge R32
Refrigerant Charge kg 1.05
