No Description Part Code Note Qty
1 Front Grill 22413046 1 AK
2 Front Panel Assy 0153305105 1 AV
3 Chassis Sub-assy 01700000013P 1 AV
4 Gas-liquid Separator 07223048 1 AU
5 Drainage Joint 26113009 1 AD
6 Compressor Gasket 76710247 3 AE
7 Compressor and Fittings 00103919G 1 BQ
8 Magnet Coil 4300040045 1 AM
9 4-Way Valve Assy 030152000293 1 AY
10 Temperature Sensor 3900007301 1 AE
11 Temperature Sensor 39000073 1 AE
12 Cut off Valve 071302391 1 AN
13 Cut off Valve 07130239 1 AK
14 Valve Cover 22242101 1 AE
15 Big Handle 2623304801 1 AE
16 Electric Expand Valve Fitting 4300034403 1 AP
17 Electric Expand Valve Fitting 4300034401 1 AU
18 PFC Inductance 43120132 1 AP
19 Clapboard Sub-Assy 01233206 1 AM
20 Temperature Sensor 3900030901 1 AH
21 Rear Grill 01473060 1 AG
22 Condenser Assy 011002000517 1 BR
23 Coping 012049000006P 1 AP
24 Motor Support Sub-Assy 01703238 1 AN
25 Left Side Plate 01303169P 1 AK
26 Electric Box Assy 100002002020 1 BQ
27 Connecting Cable 400205403 1 AN
28 Fan Motor 1501308507 1 AY
29 Axial Flow Fan 10333022 1 AP
MODEL: MV-E14BI Outdoor unit
The data are subject to change without notice.
