DIP SWITCHES CONFIGURATION
RD1 AVR has two groups of DIP switches:
The first group (group 1) of DIP switches selects the nominal voltage of sensing.
- 115 Vac
- 230 Vac
- 400 Vac
- 480 Vac
- the working frequency 50 Hz or 60 Hz
- single phase or 3 phases sensing
The second group (group 2) of DIP switches selects:
- The possibility to set generator output by External voltage (Ext V, ON)
- The possibility to set generator output by External Potentiometer (Ext P, ON)
