Singer 1100 - Powering and Connecting the Machine; Connecting to Power Source; Foot Control Operation

Polarized attachment plug
Conductor
intended to be grounded
Connect the machine to a power source as illustrated. (1)
For appliance is equipped with a polarized plug which must be
used with the appropriate polarized outlet. (2)
Unplug power cord when machine is not in use.
The foot control pedal regulates the sewing speed. (3)
Consult a qualified electrician if in doubt as to connect
machine to power source.
Unplug power cord when machine is not in use.
The foot control must be used with the appliance by 4C-
316B (110-120V area) / 4C-326G (230V area) / 4C-316C or
4C-326C (220-240V area) manufactured by Panasonic Co.,
Ltd.(TW)
Press main switch (A) for power and light on " l ".
For appliance with a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is
intended to fit in a polarized outlet only one way. If it does
not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install the proper outlet. Do
not modify the plug in any way.
Attention:
Attention:
Foot control
Sewing light
IMPORTANT NOTICE
1
2
3
6
Connecting machine to power source
A
