2 & 5 Stitch Pattern
Machines
CHOOSING AND CHANGING NEEDLES
IMPORTANT: For best sewing results, use
only Singer needles.
Loosen needle clamp screw and remove needle. With
flat side of needle to the back, insert new needle up
into clamp as far as it will go. Tighten needle clamp
screw securely.
FREE ARM SEWING
Pull end of extension table away from machine, as
illustrated.
Topstitch edges on sleeves, or finish waistbands and
pants legs easily.
ATTACHING FEED COVER
Press tab (1) and (2) into holes on needle plate.
9
