Singer 3368 - Bobbin Winding Procedure; Winding the Bobbin; Bobbin Winder Spindle Operation

Winding the bobbin
a
9
1
2
Place an empty bobbin on the bobbin winder spindle.
Take the thread from the spool through the bobbin winder
tension disc. (1)
Wind the thread a few times by hand around the empty
bobbin in a clockwise direction. Push the bobbin to the
right towards the bobbin winding position. (2)
Press the foot control gently. The bobbin will stop winding
when it is full. Push the bobbin to the left to "sewing
position" and remove it.
Please Note:
When the bobbin winder spindle is in
"bobbin winding" position, the
machine will not sew and the hand
wheel will not turn. To start sewing,
push the bobbin winder spindle to the
left (sewing position).
a. Spool pin
