Singer 6550 - Page F Page F; Description; ; 004104012*

Page F Page F
No. Part No.
Description
No. Part No.
Description
No. Part No.
Description
1 NB0693000 Bobbin shaft oil cloth 37
004104012*
Set screw (1/18*44*5) 73 E1A1873003 Spring
2 E1A2033000 Bobbin shaft 38 E1A0443003 Feed rock crank pin (1) 74 H12883000 Steel ball
3 NB0673000 Bobbin shaft washer (2) 39 E4A0223002 Feed rock crank 75 NB0495000 Lower shaft gear plate
4
003010046*
E-Ring (ETW-4) 40 E1A0453003 Feed lifting rock crank (2) 76 V11564000 Lower shaft collar complete
5 NB1275000 Shuttle hook complete 41 004240633 Feed back crank screw 77 E1A0303000 Feed lifting rock cam
6 NB0643000 Magnet 42 E1A0345000 Belt adjusting plate complete 78 E1A0323000 Feed rock cam
7 NB1265000 Shuttle hook holder 43 E1A0353000 Belt adjusting plate 79 F30283003 Feed rock shaft collar
8 NB0683000 Bobbin shaft washer (3) 44 H12323000 Belt adjusting plate pulley 80 004230433 Set screw (M3*3 C)
9 E1A0563000 Needle plate cover 45
004240585*
Set screw (M4*8)
10
004230066*
Set screw (M3*12) 46 F30333000 Feed regulating block
11 E1A0463000 Feed crank shaft 47 E1A0474000 Feed regulating plate complete
12 E1A0523000 Rotary hook holder 48 F30353000 Feed regulating
13 E1A0553000 Rotary hook holder positioned plate 49
004400570*
Endure attrition washer
14
004240056*
Set screw (M4*6 B) 50 R11443000 Feed rock bushing
15 E1A0543000 Rotary hook supporter 51
004300123*
Washer (6.7*12*1)
16
004240033*
Set screw (M4*5 C) 52
003011052*
E-Ring (ETW-5)
17
004240106*
Set screw (M4*8 A) 53 E1A0483003 Feed regulating shaft
18 K82133003 Base plate adjustment screw 54 E1A0503003 Feed regulating crank
19 H70043000 Free arm vase cushion rubber 55 E1A0493003 Feed crank
20 004840106 Adjusting nut (ALN-4) 56 E1A2503000 Free arm vase cushion rubber
21 E1A2343003 Feed regulating spring 57
004240046*
Set screw (M4*10 B)
22 E1A0373000 Feed rock shaft 58 E1A0283000 Lower shaft bushing
23 E1A0403003 Feed rock frame shaft (2) 59 NB0503000 Lower shaft gear
24
004240503*
Set screw (M4*4) 60
003010063*
E-Ring (ETW-6)
25 E1A0423003 Feed rock frame shaft (1) 61 E1A0305000 Feed lifting rock cam complete
26 E1A0383003 Feed rock bushing pin (1) 62 E1A0290000 Feed lifting rock cam
27
003010043*
E-Ring (ETW-4) 63 E1A0333003 Lower shaft spring
28
004300643*
Washer (5.2*10*0.5) 64
004300936*
Washer (8.2*12*0.5)
29 E1A2023003 Feed shaft spring 65 E1A0325000 Feed rock cam complete
30 E1A2083210 Feed rock crank 66 E1A0273000 Lower shaft
31 F30323003 Feed rock crank pin 67 V11553003 Lower shaft collar
32
004240223*
Set screw (M4*6) 68 004400830 Endure attrition washer
33
003010036*
E-Ring (ETW-3) 69 E1A0313000 Lower shaft belt pulley
34 F30284000 Feed rock shaft collar complete 70
004230673*
Set screw (M3*14.5)
35 E1A0413000 Feed rock frame 71 E1A2573003 Base plate adjustment screw spring
36 E3A0033001 Feed dog 72 E1A0573210 Feed lifting shaft
