26 Singer Inspiration
Setting
Cam controlled feed follower adjustment
1. To adjust, loosen the nut (a) and hold the slit of the shaft (b) by means a screwdriver.
2. Turn the shaft (b) to centralize the follower.
3. Tighten the nut (a).
4. Recheck and readjust if necessary.
Stitch width selector adjustment
1. Turn handwheel to the front of the machine and observe the maximum movement of zig-
zag.
2. To increase or decrease the width, loose the nut (a) and rotate the eccentric screw (b) clock-
wise or counter clockwise.
3. Tighten nut (a).
4. Recheck and readjust if necessary.
