Singer Inspiration 33
Setting
Adjusting of the thread retainer spring “M”
Check
The correct condition of the thread work is when the take up lever pull up the thread, and the
thread pass between the retainer plate (c) and the spring (d).
Adjustment
1.Make a straight stitch sew and observe the thread passing between the spring (d) and the
plate (c). If the thread does not pass correctly:
2. Loose the screw (e) and push the retainer plate in the take up lever direction, leaving ap-
proximately 1,0 mm of clearance.
3. Tighten the screw (e).
4. Repeat the procedures and readjust if necessary.
