Singer Inspiration 19
Setting
Presser bar height and alignment
Check
The presser foot (A) should be parallel to the Needle plate slot (B).
Adjustment
1. Loose the two allen screws (a) to release the position plate.
2. Move the presser bar (b) to the left or to the right until it is parallel to the needle plate slot.
3. Tighten the screws (a).
Presser bar height
Check
When the presser foot is in its highest lifting position
it shall be between 7,35 to 7,60 mm above the needle
plate.
Adjustment
1. Raise the presser foot.
2. Loose the screw (c).
3. Raise or lower the presser bar to reach the distance of
7,35 and 7,60 mm from the underside of the foot and the
surface of needle plate.
4. Tighten the screw (c) and check so the presser foot (A)
is parallel to the Needle plate slot (B).
5. Re-check and re-adjust if necessary.
