6
Winding the Bobbin
- Place thread and corresponding spool holder on to spool
pin. (1/2)
- Snap thread into thread guide. (3)
- Wind thread clockwise around bobbin winder tension
discs. (4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin spindle to right. (6)
- Hold thread end. (7)
- Step on foot control pedal. (8)
- Release the pedal after a few turns. Release the thread
and cut as close as possible to the spool. Press the pedal
again. Once the spool is full, it rotates slowly. Release the
pedal and cut thread. (9)
- Push bobbin spindle to left (10) and remove.
Please Note:
When the bobbin winder spindle is in “bobbin winding”
position, the machine will not sew and the hand wheel will
not turn. To start sewing, push the bobbin winder spindle
to the left (sewing position).
