Singer One Plus - Page 15

Page 15/41
Original issue
Oct.2012
Service Manual
One Plus
Model
5. Needle threader height --continued--
7. If the direction of insert hook is deviated from correct position, adjust the hook
position with the small screw driver in the accessory.
8. If hook protrudes from needle hole too much or little, it may affect threading
condition.
Hook protrudes
too much.
Hook protrudes
correctly.
Hook protrudes
too little.
Needle
Hook
Hook holder
Needle hole
Hook
Hook
