Singer One Plus - Page 19

Page 19/41
Original issue
Oct.2012
Service Manual
One Plus
Model
7. Needle position at zigzag stitching
Checking:
1. Set test mode at 1.
2. Turn hand wheel by hand and see if needle leaves the same clearance at both right
and left end of needle plate hole.
Adjustment:
1. Loosen screw (A) and adjust needle position.
b
a
a＝b
A
