A
C
B
Maintenance – 31
English
MAINTENANCE
Cleaning the Machine
Cleaning the Bobbin Area
Raise the needle and turn o the machine.
Raise the needle and turn o the machine.
Cleaning under the Bobbin Area
To keep your sewing machine operating well, clean it often. No lubrication (oiling) is needed. Wipe the exterior surface of your ma-
chine with a soft cloth to remove any dust or lint built up.
Remove the presser foot. Slide o the bobbin cover and re-
move the bobbin.
Remove the screws in the needle plate by using the L-screw-
driver. Lift up and remove the needle plate.
Clean the feed teeth and the bobbin area with the brush found
among the accessories.
Place the needle plate over the feed teeth, replace and tighten
the screws.
Attach the presser foot, insert the bobbin and replace the bob-
bin cover.
Clean the area under the bobbin case after sewing several
projects or any time you notice an accumulation of lint in the
bobbin case area.
Remove the presser foot. Slide o the bobbin cover and re-
move the bobbin.
Remove the screws in the needle plate by using the L-screw-
driver. Lift up and remove the needle plate.
Remove the bobbin case by lifting it up. This is easier if you
push it slightly to the left or right as you lift.
Clean the area with the brush or with a dry cloth.
Note: Do not blow air into the bobbin case area. The dust and
lint will be blown into your machine.
Guide the “forked” end of the bobbin case (A) under the bob-
bin case holder (B) and under the feed teeth. Move the bob-
bin case slightly from right to left until it slips correctly into
the hook race (C). To make sure the bobbin case is properly
replaced, turn the handwheel towards you. The hook race (C)
should rotate freely in a counter-clockwise direction.
Place the needle plate over the feed teeth, replace and tighten
the screws.
Attach the presser foot, insert the bobbin and replace the bob-
bin cover.
