Singer S800 - Winding the Bobbin

16
WINDING THE BOBBIN
1. Place a spool of thread on the spool pin, and secure it with
the spool pin cap. Pull the thread out from the spool and
place it through thread guides as shown in illustration.
Be sure to pull thread securely into the bobbin winding
tension disk.
2. Put end of thread through the hole in bobbin as shown.
Push bobbin winder shaft to far left position, if it is not
already there.
3. Place bobbin onto shaft with end of thread coming from
top of bobbin. Push bobbin winder shaft to the right until it
clicks. Hold the end of thread.
4. Start machine and the bobbin starts to wind. Stop to trim
the thread tail, then step on the foot controller to resume
winding. Bobbin will automatically stop turning when
FRPSOHWHO\¿OOHG3XVKVKDIWWRWKHOHIWWRUHPRYHEREELQ
and cut thread.
2
3
4
1
Be sure to use only Class 15J bobbins.
