Singer XL-5000 - Page 11

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
#7
DRIVE SHAFT FIXING PLATE (TOTAL ASM.)
1
2
387614
HOLDING PRESSURE CHANGE-OVER CONTACT PLATE
(1)
3
283489
SCREW
(1)
4
387615
DRIVE RACK
(1)
5
283489
SCREW
(2)
6
387616
TOP THREAD TRANSFER BODY CONTROL CAM
(1)
7
386495
SCREW
(1)
8
387390
SCREW
(1)
9
387617
TOP THREAD TRANSFER INTERMEDIATE GEAR A
(1)
10
387618
TOP THREAD TRANSFER INTERMEDIATE GEAR B
(1)
11
283458
E RING
(2)
12
387341
TOP THREAD TRANSFER BODY (TOTAL ASM.)
(1)
13
*
387619
TOP THREAD TRANSFER BODY (ASM.)
(1)
14
*
387622
THREAD PRESSER (ASM.)
(1)
15
*
387647
THREAD PRESSER WASHER
(1)
16
*
387643
THREAD PRESSER SPRING
(1)
17
*
387386
E RING
(1)
18
*
387624
HOLDING PRESSURE CHANGE-OVER PLATE
(1)
19
*
387623
HINGE SCREW
(1)
20
*
387625
HOLDING PRESSURE CHANGE-OVER LINK (ASM.)
(1)
21
*
283458
E RING
(2)
22
387627
CHANGE-OVER WORKING PLATE (TOTAL ASM.)
(1)
23
*
#5
CHANGE-OVER WORKING PLATE (ASM.)
(1)
24
*
#5
HOLDING PRESSURE CHANGE-OVER ROLLER
(1)
25
*
#5
CHANGE-OVER ROLLER SPRING
(1)
26
*
#5
E RING
(1)
27
*
283458
E RING
(1)
28
*
387630
HOLDING PRESSURE CHANGE-OVER ADJUST PLATE
(1)
29
283489
SCREW
(1)
30
387631
CHANGE-OVER WORKING PLATE SPRING
(1)
31
387620
TOP THREAD TRANSFER BODY FULCRUM BASE
(1)
32
387621
TOP THREAD TRANSFER BODY STOPPER
(1)
33
283489
SCREW
(1)
34
283489
SCREW
(2)
35
387649
WASHER
(1)
36
387632
EXTERNAL WORKING BODY (ASM.)
(1)
37
#6
EXTERNAL WORKING BODY BEARING
(1)
38
387633
EXTERNAL WORKING BODY GUIDE
(1)
39
387650
SCREW
(1)
40
#6
INTERNAL WORKING BODY
(1)
41
#6
WORKING BODY SPRING
(1)
42
#7
THREADING WORKING PLATE (ASM.)
(1)
43
387637
WORKING BODY ROLLER
(1)
44
387411
SCREW
(2)
45
387638
TOP THREAD TRANSFER BODY CAM
(1)
46
387639
TOP THREAD TRANSFER BODY SPRING
(1)
47
387640
TOP THREAD TRANSFER COLLAR
(1)
48
283506
SCREW
(1)
49
387644
THREAD TRANSFER BODY DETECT BOARD GUIDE
(1)
50
386495
SCREW
(1)
51
387641
THREAD TRANSFER BODY DRIVE SHAFT
(1)
52
283460
E RING
(1)
53
387382
THREAD TRANSFER BODY DRIVE SHAFT PIN
(1)
54
387642
THREAD TRANSFER BODY DRIVE SHAFT GEAR
(1)
55
387645
THREADING STM
(1)
56
283491
SCREW
(2)
57
387646
THREAD TRANSFER BODY DETECT CIRCUIT BOARD (ASM.)
(1)
58
387613
DRIVE SHAFT FIXING PLATE (ASM.)
(1)
59
387006
BAND
(1)
60
#6
WORKING BODY SPRING (LOWER)
(1)
61
387502
LIFTING LEVER (ASM.)
1
62
#8
LIFTING LEVER SHAFT
(1)
63
383883
LIFTING LEVER SPRING
(1)
64
#8
LIFTING LEVER
(1)
65
#8
E RING
(2)
66
387500
PRESSER SPRING
1
67
283097
POSITION BRACKET SETSCREW HOLDER
1
68
283515
SCREW
1
69
387505
PRESSER HOLDER (ASM.)
1
70
387506
STANDARD PRESSER FOOT
1
71
386143
SCREW
1
72
283511
SCREW
1
73
387503
PRESSER BAR GUIDE
1
74
283502
SCREW
2
75
387499
PRESSER BAR
1
FOR THE PARTS TO WHICH "#" IS WRITTEN IN THE PART NO. COLUMN,
REFER TO THE LIST AT THE END OF PARTS LIST.
- 8 -
