REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387447
MAIN SHAFT (ASM.)
1
2
387409
SCREW
(2)
3
283045
MAIN SHAFT BUSHING
1
4
386095
MAIN SHAFT THRUST COLLAR (ASM.)
1
5
386523
SCREW
(2)
6
283464
E RING
1
7
387450
DISENGAGING CAM SPRING
1
8
387452
MAIN SHAFT DISENGAGING CAM (ASM.)
1
9
387453
MAIN SHAFT DISENGAGING STOPPER SPRING
(1)
10
283522
SCREW
(1)
11
387454
MAIN SHAFT DISENGAGING CAM PIN
1
12
387608
THREAD TAKE-UP BODY (ASM.)
1
13
283051
ENDSCREW (LEFT)
1
14
*
387457
MAIN SHAFT PULLEY (ASM.)
1
15
*
387456
MAIN SHAFT PULLEY
(1)
16
*
387459
MAIN SHAFT DISENGAGING BUFFER LINK
(1)
17
*
387460
MAIN SHAFT DISENGAGING BUFFER SPRING
(1)
18
*
387464
BUFFER MATERIAL
(1)
19
*
387461
MAIN SHAFT DISENGAGING CAM LATCH SPRING
(1)
20
*
283522
SCREW
(1)
21
283464
E RING
1
22
387451
MAIN SHAFT BUSHING (REAR)
1
23
387458
HAND WHEEL
1
24
283054
SCREW
1
25
387462
WASHER
1
26
387715
SPRING WASHER
2
27
283046
MAIN SHAFT BUSHING RETAINING PLATE
1
28
387463
MAIN SHAFT BUSHING RETAINING PLATE (REAR)
1
29
283502
SCREW
2
30
387611
THREAD TAKE-UP SUPPORT
1
31
387610
TAKE-UP SUPPORTING SHAFT (ASM.)
1
32
387609
THREAD TAKE-UP LEVER SUPPORTING SHAFT
(1)
33
283462
E RING
(1)
34
387612
TAKE-UP SUPPORTING SHAFT RETAINING PLATE
1
35
387142
SCREW
1
36
387448
NEEDLE BAR CRANK
1
37
387468
NEEDLE BAR CRANK ROD
1
38
#13
WASHER
1
39
388024
IDLER (ASM.)
1
40
*
388023
IDLER
(1)
41
*
388025
IDLER FIXING PLATE (ASM.)
(1)
42
*
283460
E RING
(1)
43
387404
SCREW
1
44
388017
TIMING BELT (LARGE)
1
45
387455
MAIN SHAFT THRUST SPRING WASHER
1
FOR THE PARTS TO WHICH "#" IS WRITTEN IN THE PART NO. COLUMN,
REFER TO THE LIST AT THE END OF PARTS LIST.
