REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387845
FRONT PANEL (ASM.) "QUANTUM"
1
2
388089
FROMT PANEL (ASM.) "PROFESSIONAL"
1
3
388113
FROMT PANEL (ASM.) "FUTURA TOP"
1
4
387844
FRONT PANEL "QUANTUM"
(1)
5
388090
FRONT PANEL "PROFESSIONAL"
(1)
6
388114
FRONT PANEL "FUTURA TOP"
(1)
7
387342
SWITCH/SLIDE VOLUME BOARD (ASM.)
(1)
8
283355
BAND
(1)
9
283522
SCREW
(2)
10
283522
SCREW
(1)
11
387863
WITH/WITHOUT BOBBIN THREAD SENSOR SHIELD PLATE
(1)
12
387864
SPRING
(1)
13
283335
START SWITCH LEAD TAPE
(3)
14
387889
BLIND PLATE
(1)
15
283478
SCREW
(2)
16
283522
SCREW
(2)
17
283523
SCREW
(4)
18
387343
LCD MODULE (TOTAL ASM.)
(1)
19
387866
LCD MODULE (ASM.)
(1)
20
387846
LCD FIXING PLATE
(1)
21
283522
SCREW
(2)
22
387849
TRANSPARENT TOUCH PANEL (ASM.)
(1)
23
387848
TRANSPARENT TOUCH PANEL
(1)
24
387850
SWITCH SHEET
(1)
25
387851
DOUBLE SIDE ADHESIVE TAPE
(2)
26
387872
INVERTER CIRCUIT BOARD (ASM.)
(1)
27
283522
SCREW
(2)
28
387882
DISPLAY CIRCUIT BOARD RELAY LEAD WIRE
(1)
29
387852
TTP BUFFER MATERIAL (VERTICAL)
(3)
30
387854
BOBBIN THRESD THREAD STAND ROD
(1)
31
387860
FELT
(1)
32
387383
PIN
(1)
33
283522
SCREW
(1)
34
386078
THREAD SPOOL CAP
(1)
35
387853
BOBBIN THREAD SPOOL COVER
(1)
36
387855
SPOOL COVER HOOK
(1)
37
283522
SCREW
(1)
38
387423
WASHER
(1)
39
387857
BOBBIN THREAD THREAD GUIDE (TOTAL ASM.)
(1)
40
*
387856
BOBBIN THREAD THREAD GUIDE (ASM.)
(1)
41
*
387386
E RING
(1)
42
*
387413
WASHER
(1)
43
*
387858
THREAD GUIDE PLATE SPRING
(1)
44
*
387859
THREAD GUIDE SPRING
(1)
45
283522
SCREW
(1)
46
387865
EMBROIDERY BOBBIN WINDER SEAL
(1)
47
283522
SCREW
(1)
48
387861
THREAD GUIDE COVER
(1)
49
387862
THREAD GUIDE ROD
(1)
50
387411
SCREW
(1)
51
387154
SCREW
(2)
52
283469
SCREW
(1)
53
387847
LCD FIXING COLLAR
(2)
54
387869
THREAD TRIMMING BUTTON
(1)
55
387867
S/S BUTTON
(1)
56
387868
REVERSE BUTTON
(1)
57
387870
HALF-STITCH BUTTON
(1)
58
387888
SLIDE VR KNOB
(1)
- 12 -
