REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387475
NEDDLE BAR FRAME (COMPL.)
1
2
387474
NEDDLE BAR FRAME (PARTIAL ASM.)
(1)
3
*
387473
NEEDLE BAR FRAME
(1)
4
*
387489
THREADING SHAFT DUMPER RING
(1)
5
*
387477
NEEDLE BAR ROCKER BASE SHAFT
(1)
6
*
387479
ROCKER BASE FULCRUM SHAFT
(1)
7
283506
SCREW
(1)
8
*
387491
THREADER WORKING BODY SPRING HOOK
(1)
9
387465
NEEDLE BAR (ASM.)
(1)
10
*
387484
THREADER SHAFT
(1)
11
283459
E RING
(1)
12
*
387485
PIN
(1)
13
*
387487
NEEDLE STOPPER THREADING BODY
(1)
14
*
387488
NEEDLE STOPPER THREADING BODY SPRING
(1)
15
*
387476
THREADER SHAFT GUIDE
(1)
16
*
#7
THREADER WORKING BODY
(1)
17
*
283506
SCREW
(1)
18
*
387477
CONNECTING PLATE SHAFT
(1)
19
387467
NEEDLE CLAMP (TOTAL ASM.)
(1)
20
387379
NEEDLE #15
(1)
21
387469
NEEDLE BAR CONNECTION (ASM.)
(1)
22
387471
THREADER NEEDLE BAR GUIDE (ASM.)
(1)
23
*
387470
THREADER NEEDLE BAR GUIDE
(1)
24
*
387472
TRANSFER BODY POSITIONING PLATE
(1)
25
*
283511
SCREW
(1)
26
*
283470
SCREW
(1)
27
387492
FELT
(1)
28
387344
NEEDLE THREADER HOOK HOLDER (ASM.)
(1)
29
387398
SCREW
(1)
30
387486
NEEDLE THREADER SHAFT SPRING
(1)
31
387490
NEEDLE STOPPER THREADING ARM
(1)
32
386528
SCREW
(1)
33
387483
ROCKING BASE SPRING (LOWER)
(1)
34
283073
THREAD RELEASE CAM SPRING
(1)
35
387482
SPRING
(1)
36
387493
FELT HOLDER
(1)
37
385337
SCREW
(1)
38
388137
NEEDLE BAR REGULATION SPRING
(1)
39
387481
ROCKING BASE SHAFT SPRING
1
40
283491
SCREW
2
41
387480
ROCKING BASE ADJUST SHAFT
1
42
387466
NEEDLE MIS-INSERT PREVENTING PLATE
1
43
387494
SCREW
1
44
386927
SCREW
1
45
388108
NEEDLE THREADER EXCHANGE HOOK HOLDER (TOTAL ASM.)
1
FOR THE PARTS TO WHICH "#" IS WRITTEN IN THE PART NO. COLUMN,
REFER TO THE LIST AT THE END OF PARTS LIST.
