REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
#2
FACE PLATE FIXING PLATE (TOTAL ASM.)
1
2
#2
FACE PLATE FIXING PLATE (ASM.)
(1)
3
*
#2
FACE PLATE FIXING PLATE
(1)
4
*
387497
NEEDLE BAR LATERAL ADJUST PLATE (SASM.)
(1)
5
*
283502
SCREW
(1)
6
387841
LAMP FIXING BODY
(1)
7
386520
SCREW
(1)
8
387842
LAMP SEAL
(1)
9
387840
LAMP (ASM.)
(1)
10
387346
BULB
(1)
11
283527
WASHER
(1)
12
387498
ROCKING BASE CONTROL ARM
(1)
13
283459
E RING
(1)
14
283469
SCREW
(1)
15
387006
BAND (SMALL)
(2)
16
387651
CONTROL PLATE
(1)
17
387392
SCREW
2
18
#10
FACE PLATE (ASM.)
1
19
387757
FACE PLATE PILE
(1)
20
387766
FACE PLATE INSIDE COVER FIXING PLATE
(1)
21
387772
FACE PLATE TENSION PILE
(1)
22
387724
NEEDLE THREAD BREAKAGE DETECTING BOARD (ASM.)
(1)
23
387771
FEED BAR PILE
(1)
24
387725
THREAD TAKE-UP SPRING
(1)
25
387737
NEEDLE THREAD BREAKAGE DETECT SHIELD PLATE
(1)
26
387758
THREAD TAKE-UP SPRING FIXING PLATE
(1)
27
283495
SCREW
(1)
28
387767
THREAD TAKE-UP SPRING CUSHION
(1)
29
283491
SCREW
(1)
30
387759
MIS-THREADING PREVENTING PLATE (ASM.)
(1)
31
283459
E RING
(1)
32
387760
SPRING
(1)
33
387753
DELIVERY ROLLER PILE
(1)
34
387761
THREAD TAKE-UP GUIDE
(1)
35
385340
SCREW
(1)
36
#2
FACE PLATE REINFORCING PLATE
(1)
37
283491
SCREW
(1)
38
387768
FACE PLATE TENSION BASE (ASM.)
(1)
39
386502
SCREW
(1)
40
#3
DELIVERY ROLLER PILE
(1)
41
387006
BAND (SMALL)
(1)
42
#10
FACE PLATE
(1)
43
387392
SCREW
1
FOR THE PARTS TO WHICH "#" IS WRITTEN IN THE PART NO. COLUMN,
REFER TO THE LIST AT THE END OF PARTS LIST.
