Singer XL-5000 - Page 23

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387601
GEAR COVER (ASM.)
1
2
*
387600
GEAR COVER
(1)
3
*
387571
WINDING-ROUND PREVENTING KNIFE
(1)
4
*
385335
SCREW
(1)
5
283491
SCREW
1
6
387394
SCREW (RIGHT)
1
7
387350
BOBBIN CASE STOPER PLATE (ASM.)
1
8
*
387576
BOBBIN CASE STOPPER PLATE
(1)
9
*
385212
INTER-HOOK HOLDING PLATE SPRING
(1)
10
*
385335
SCREW
(1)
11
*
387806
BOBBIN WINDER BASE TENSION (ASM.)
(1)
12
*
387807
SPRING
(1)
13
*
387386
E RING
(1)
14
*
387572
STOPPER PLATE SUPPORT
(1)
15
387713
KNIFE DISENGAGING LINK
1
16
387590
THREAD TRIMMING MECHANISM BASE (ASM. B)
1
17
387589
THREAD TRIMMING MECHANISM BASE (ASM. A)
(1)
18
387583
LOOPER WORKING PLATE (ASM.)
(1)
19
387587
MOVING KNIFE BASE GUIDE
(1)
20
283488
SCREW
(1)
21
386502
SCREW
(1)
22
387599
MOVING KNIFE STOPPER
(1)
23
387586
MOVING KNIFE BASE (TOTAL ASM.)
1
24
*
387585
MOVING KNIFE BASE (ASM.)
(1)
25
*
387351
MOVING KNIFE
(1)
26
*
387588
SPACER
(1)
27
*
387596
SCREW
(2)
28
283460
E RING
2
29
387591
MOVING KNIFE GUIDE PLATE (UPPER)
1
30
387592
MOVING KNIFE GUIDE PLATE (LOWER)
1
31
387593
SPACER
1
32
387597
MOVING KNIFE SUPPORT
1
33
386240
GUIDE PLATE COLLAR
1
34
385340
SCREW
1
35
387401
SCREW
1
36
387594
MOVING KNIFE LINK
1
37
387595
SPRING
1
38
283528
WASHER
1
39
283460
E RING
1
40
387598
MOVING KNIFE SUPPORT (LEFT)
1
41
386505
SCREW
1
42
387708
KNIFE DRIVE LINK (ASM.)
1
43
387707
SPRING
1
44
283460
E RING
2
45
387709
KNIFE DIENGAGING PLATE (ASM.)
1
46
283459
E RING
1
47
387711
KNIFE DISENGAGING ADJUST PLATE (ASM.)
1
48
387710
KNIFE DISENGAGING ADJUST PLATE
(1)
49
387712
KNIFE DISENGAGING ADJUST PLATE (FRONT)
(1)
50
283486
SCREW
(1)
51
387140
SCREW
2
52
387541
LOOPER (ASM.)
1
53
*
387540
LOOPER
(1)
54
*
387544
LOOPER ATTACHING PLATE (LEFT)
(1)
55
*
387542
LOOPER ADJUSTING PLATE
(1)
56
*
387548
LOOPER SHAFT (LEFT)
(1)
57
*
387546
SPRING
(1)
58
*
387407
SCREW
(1)
59
*
283459
E RING
(1)
60
*
283478
SCREW
(1)
61
*
387414
WASHER
(1)
62
*
387547
SPRING
(1)
63
283491
SCREW
1
64
387584
SPRING
1
65
387543
LOOPER ATTACHING PLATE (RIGHT) (ASM.)
1
66
283458
E RING
1
67
387603
REMAINING AMOUNT SENSOR FIXING BASE (RECEIVE LIGHT)
1
68
387605
REMAINING AMOUNT SENSOR BOARD (RECEIVE LIGHT) (ASM.)
1
69
283486
SCREW
1
70
387436
SCREW
1
71
386520
SCREW
1
72
283497
SCREW
1
73
387399
SCREW
1
- 20 -
