Singer XL-5000 - Page 25

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387518
FEED ROCKER ARM (TOTAL ASM.)
1
2
388144
FEED ROCKER ARM SHAFT
(1)
3
*
387517
FEED ROCKER ARM (LARGE)
(1)
4
*
283502
SCREW
(2)
5
388162
FEED BAR (ASM.)
(1)
6
*
387514
FEED BAR SHAFT (LEFT)
(1)
7
283491
SCREW
(2)
8
387509
VERTICAL FEED ADJUST SHAFT
(1)
9
387511
VERTICAL FEED ECCENTRIC SHAFT
(1)
10
283511
SCREW
(1)
11
387528
FEED DOG
(1)
12
387516
FEED BAR SHAFT (RIGHT)
(1)
13
283506
SCREW
(1)
14
387581
DF LINK
(1)
15
387582
SPRING
(1)
16
283462
E RING
(1)
17
387512
FEED ROCKER ARM (SMALL)
(1)
18
283514
SCREW
(1)
19
387519
FORKED ROD
(1)
20
387515
FORKED ROD SHAFT
(1)
21
283506
SCREW
(1)
22
283460
E RING
(1)
23
387520
SPRING
(1)
24
387524
FEED REGULATOR BLOCK SHAFT
(1)
25
283506
SCREW
(1)
26
387552
LATERAL FEED WORKING PLATE
(1)
27
283186
HOOK DRIVING BUSHING
(1)
28
387424
SPRING WASHER
(1)
29
283462
E RING
(2)
30
387513
FEED BAR SPRING
(1)
31
387771
FEED BAR PILE
(1)
32
387523
FEED REGULATOR BLOCK
(1)
33
388145
FEED BAR BRUSH
(1)
34
283186
HOOK DRIVING BUSHING
1
35
387531
FEED STM FIXING PLATE (COMPL.)
1
36
387530
FEED STM FIXING PLATE (ASM.)
(1)
37
387529
FEED STM FIXING PLATE
(1)
38
387536
FEED STOPPER SHAFT
(1)
39
387534
FEED STM GEAR (ASM.)
(1)
40
283506
SCREW
(2)
41
283488
SCREW
(2)
42
387522
FEED REGULATOR (ASM.)
(1)
43
387521
FEED REGULATOR
(1)
44
386172
FEED REGULATOR GEAR A
(1)
45
386173
FEED REGULATOR GEAR B
(1)
46
387525
SPRING
(1)
47
283488
SCREW
(1)
48
387527
FEED REGULATOR SHAFT
(1)
49
283528
WASHER
(1)
50
283503
SCREW
(1)
51
283451
NUT
(1)
52
387533
ORIGIN DETECTING RUBBER
(1)
53
387352
FEED STM
(1)
54
387538
FEED STM RELAY LEAD IRE (ASM.)
(1)
55
387537
SPRING
(1)
56
387535
LEVER
(1)
57
283459
E RING
(1)
58
#11
HOOK DRIVING SHAFT (ASM.)
1
59
388147
HOOK DRIVING SHAFT SUPPORT B (ASM.)
(1)
60
283473
SCREW
(1)
61
#11
HOOK DRIVING SHAFT (ASM.)
(1)
62
387150
WASHER
(1)
63
387564
HOOK DRIVING GEAR
(1)
64
386488
THREAD TRIMMING CAM SPRING PIN
(1)
65
387539
VERTICAL FEED CAM
(1)
66
387385
STOP PIN
(1)
67
387510
FEED ROCKER CAM
(1)
68
283462
E RING
(1)
69
387449
MAIN SHAFT DETECTOR SHIELD PLATE
(1)
70
283473
SCREW
(1)
71
385137
THRUST COLLAR (ASM.)
(1)
72
283511
SCREW
(2)
73
283186
HOOK DRIVING BUSHING
(1)
74
387705
THREAD TRIMMING CAM
(1)
75
387562
HOOK DRIVING SHAFT
(1)
76
387706
PIN
(1)
77
387381
NUT
(1)
78
386488
THREAD TRIMMING CAM SPRING PIN
(1)
79
387565
HOOK DRIVING SHAFT PULLEY (ASM.)
1
80
283511
SCREW
(2)
81
386216
BALL BEARING GUARD PLATE (REAR)
2
82
283502
SCREW
2
83
387526
FEED REGULATOR SHAFT STOP PLATE
1
84
283502
SCREW
1
85
283355
BAND
1
86
387568
HOOK DRIVING SHAFT ECCENTRIC BUSHING
1
87
387567
BALL BEARING GUARD PLATE (FRONT)
1
88
386216
BALL BEARING GUARD PLATE (REAR)
1
89
283502
SCREW
3
90
388148
NUT A
1
91
283451
NUT B
1
FOR THE PARTS TO WHICH "#" IS WRITTEN IN THE PART NO. COLUMN,
REFER TO THE LIST AT THE END OF PARTS LIST.
- 22 -
