Singer XL-5000 - Page 27

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387574
HOOK (TOTAL ASM.)
1
2
387353
ROTATING HOOK (TOTAL ASM.)
(1)
3
*
#12
ROTATING HOOK (PARTIAL ASM.)
(1)
4
*
387395
SCREW
(1)
5
*
387578
HOOK OF ROTATING HOOK
(1)
6
*
387400
SCREW
(1)
7
*
387579
TOP THREADING CUTTER FIXING BASE
(1)
8
387338
TOP THREADING CUTTER
(1)
9
*
387396
SCREW
(1)
10
#12
HOOK SHAFT (ASM.)
(1)
11
387570
WASHER (UPPER)
(1)
12
387575
ROTATING HOOK MAGNET (ASM.)
(1)
13
387580
SPRING
(1)
14
385336
SCREW
(1)
15
387354
BOBBIN CASE (TOTAL ASM.)
(1)
16
386230
NEEDLE PLATE PILE B
(1)
17
385352
WASHER
1
18
387714
LINK COVER
1
19
#11
BOBBIN THREAD MECHANISM BASE (ASM.)
1
20
387355
BOBBIN THREAD SUPPLY STM (ASM.)
1
21
387789
BOBBIN THREAD INTERMEDIATE GEAR
1
22
387790
BOBBIN WINDER DRIVE PLATE RACK
1
23
283460
E RING
2
24
387791
BOBBIN WINDER DRIVE PLATE
1
25
283460
E RING
2
26
387792
SPRING
1
27
387793
GEAR CONNECTING LINK STOPPER
1
28
387794
SPRING
1
29
283486
SCREW
1
30
387795
GEAR CONNECTING LINK (ASM.)
1
31
*
387796
GEAR CONNECTING LINK PLATE SPRING
(1)
32
283469
SCREW
(1)
33
283459
E RING
(1)
34
387797
NEEDLE THREAD CATCHING PLATE
1
35
283486
SCREW
1
36
387577
HOOK SHAFT BASE (ASM.)
1
37
387408
SCREW
(1)
38
387602
GEAR COVER FIXING SHAFT A
2
39
387799
THREAD HOLDING PLATE (B)
1
40
387800
THREAD HOLDING PLATE SHAFT A
1
41
387801
THREAD HOLDING PLATE SHAFT B
1
42
387798
THREAD HOLDING PLATE C
1
43
387406
SCREW
2
44
387357
THREAD HOLDING PLATE (TOTAL ASM.)
1
45
*
387802
THREAD HOLDING PLATE (ASM.)
(1)
46
*
387413
WASHER
(1)
47
*
387803
BOBBIN WINDER TENSION PLATE (ASM.)
(1)
48
*
387804
SPRING
(1)
49
*
387386
E RING
(1)
50
*
387805
THREAD HOLDING SPRING
(1)
51
*
385335
SCREW
(1)
52
*
387414
WASHER
(1)
53
387406
SCREW
1
54
#11
HOOK DRIVING SHAFT SUPPORT OF HOOK
1
55
#11
SCREW
1
56
387356
BOBBIN THREAD ORIGIN SENSOR BOARD (ASM.)
1
57
*
387808
THREAD HOLDING PLATE COVER SENSOR BOARD
(1)
58
387006
BAND (SMALL)
1
59
387607
REMAINING AMOUNT SENSOR FIXING PLATE
1
60
387604
FIXING PLATE (GIVE LIGHT)
1
61
387606
REMAINING AMOUNT SENSOR BOARD (GIVE LIGHT) (ASM.)
1
62
387400
SCREW
1
63
283491
SCREW
1
64
283502
SCREW
1
65
283480
SCREW
4
66
283322
CORD HOLDER
1
67
387006
BAND (SMALL)
1
68
283491
SCREW
2
69
#11
HOOK DRIVING SHAFT SUPPORT A FITTING PLATE
1
70
#11
HOOK DRIVING SHAFT SUPPORT A
1
71
#11
SCREW
1
72
#11
SCREW
2
FOR THE PARTS TO WHICH "#" IS WRITTEN IN THE PART NO. COLUMN,
REFER TO THE LIST AT THE END OF PARTS LIST.
- 24 -
