REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387495
ROCKING ROD
1
2
283469
SCREW
2
3
386118
ECCENTRIC COLLAR
1
4
283471
SCREW
1
5
387750
THREAD RELEASE LINK (LOWER)
1
6
387652
NEEDLE ROCKER STM FIXING PLATE (ASM.)
1
7
387656
MAIN SHAFT DISENGAGING LINK (ASM.)
1
8
387655
MAIN SHAFT DISENGAGING LINK
(1)
9
387662
BUFFER SPRING
(1)
10
283460
E RING
1
11
387657
NEEDLE ROCKER CAM
1
12
283460
E RING
1
13
387658
NEEDLE ROCKER LINK
1
14
387659
MAIN SHAFT DISENGAGING STOPPER
1
15
283474
SCREW
1
16
283460
E RING
1
17
387496
ROCKING ROD A (ASM.)
1
18
283459
E RING
1
19
387358
NEEDLE BAR ROCKING STM
1
20
387653
RELAY LEAD WIRE (ASM.)
1
21
387654
NEEDLE BAR ROCKING STM GEAR (ASM.)
1
22
283506
SCREW
(2)
23
283470
SCREW
2
24
387661
DISENGAGING DETECTING BOARD (ASM.)
1
25
283470
SCREW
1
26
387532
ORIGIN DETECTING RUBBER
1
27
387660
DISENGAGING LINK SPRING
1
28
283355
BAND
1
29
283322
CORD HOLDER
1
30
283502
SCREW
3
31
387746
THREAD RELEASE LINK PLATE (ASM.)
1
32
*
387745
THREAD RELEASE LINK PLATE
(1)
33
*
387747
THREAD RELEASE LINK ADJUST PLATE
(1)
34
283470
SCREW
(1)
35
*
387748
THREAD RELEASE LINK SHAFT
(1)
36
283461
E RING
(2)
37
387403
SCREW
2
38
387778
BOBBIN WINDER MECHANISM BASE (TOTAL ASM.)
1
39
387777
BOBBIN WINDER MECHANISM BASE (ASM.)
(1)
40
*
387776
BOBBIN WINDER MECHANISM BASE
(1)
41
*
387779
BOBBIN WINDER BASE (ASM.)
(1)
42
283308
RUBBER RING
(1)
43
283523
SCREW
(1)
44
386324
SPRING
(1)
45
*
387780
GUIDE
(1)
46
283355
BAND
(1)
47
387784
BOBBIN WINDER SWITCH (ASM.)
(1)
48
283485
SCREW
(1)
49
283502
SCREW
1
50
387782
BOBBIN WINDER SHAFT (ASM.)
1
51
387783
PIN
(1)
52
*
387781
BOBBIN WINDER SHAFT
(1)
53
386325
SPRING
(1)
- 26 -
